ICAP/4Students

ICAP/4Students

integrated schematic entry, powerful SPICE simulation, models, graphical waveform processing

Features Description

Schematic Entry SpiceNet has no limitations and is the same as the production version. However, IsSpice4 will only accept SPICE netlists with fewer than 20 top-level components.

Ease-of-Use Includes Analysis and Convergence Wizards, Tutorial Help Movies, interactive Cross-probing, automatic parameter sweeping/curve family generation and custom SPICE attribute dialogs.

Model Library 1,500+parts

Data Analysis Full data analysis capability including cross-probing, display, printing, waveform measurements, cursor measurements and waveform math.

SPICE Simulator

Circuit Size Limited to 20 main circuit (top-level) elements, special limitations are applied to subcircuits.

Interactive Features Yes. You can change values and run different analyses interactively using the SpiceNet - IsSpice4 interface.

Real-Time Display Yes. You can add, delete, and rescale waveforms as the simulation runs.

Analysis Types AC, DC, Operating point, Temperature, Fourier, and Transient

Elements All SPICE 2 and SPICE 3 elements

Behavioral Models Yes. Inline Equations, Laplace, If-Then-Else, Boolean Logic, and X-Y Tables

The key difference between the demonstration version of ICAP/4Windows and the ICAP/4Students version
is that ICAP/4Students comes with a printed manual.

Software/Hardware Requirements: Windows 98SE/ME or NT/2000/XP, and requires 128 Megs of RAM and 30 Megs hard disk space.
